EOS Gracil series 9.0 kW
Точные сроки и условия подтвердит менеджер перед оплатой.
Отправить конфигурацию товара менеджеру и обсудить детали
Описание товара
EOS Gracil Floor-standing لتاريخ
Model for the Finnish (dry) sauna. Very space-saving construction — only 25 cm depth. Thanks to the recessed terminal box and optional rear wall cover Panel, ideal for placement in front of glass panels.
Optional accessories for EOS Gracil
black Guard rail optional Guard rail optional rear wall cover panel optional rear wall cover panel (black) optional
EOS Gracil W Wall-mounting
Model for the Finnish (dry) sauna. Very space-saving construction — only 27,5 cm total depth (incl. 3 cm wall gap).
Optional accessories for EOS Gracil W
black Guard rail optional EOS Gracil W black — Guard rail optional
EOS Bi-O Gracil Floor-standing
Floor-standing model with integrated vaporizer for flexible climate пушеност. Very space-saving construction — only 25 cm depth. Thanks to the recessed terminal box and optionalorgd rear wall cover Panel, ideal for placement in front of glass panels.
Optional accessories for EOS Bi-O Gracil
black rear wall cover panel optional rear wall cover panel (black) optional
EOS Bi-O Gracil W Wall-mounting
Wall-mounting model with integrated vaporizer for flexible climate forms. Very space-saving construction — only 27,5 cm total depth (incl. 3 cm wall gap).
Optional accessories for EOS Bi-O Gracil W
EOS Bi-O Gracil W black EOS Bi-O Gracil W black
Характеристики
- Мощность
- 9,0 kW
- Electrical connection
- 400 V 3N ~ 50/60 Hz
- Fuse protection (control unit)
- 3 x 16 A
- Dimensions H/W/D, in cm
- 76 / 50,5 / 25 (EOS Gracil) 74 / 50,5 / 27,5 (EOS Gracil W)
- For sauna cabin size (6,0 / 7,5 / 9,0 kW)
- 6 - 8 m³ / 7 - 10 m³ / 9 - 14 m³
- Min. size air inlet and outlet (6,0 / 7,5 / 9,0 kW)
- 35 x 5 cm / 35 x 6 cm / 35 x 6 cm
- Weight withouth rocks (6,0 / 7,5 / 9,0 kW)
- 20,5 kg / 21,0 kg / 21,5 kg (EOS Gracil) 20,6 kg / 21,1 kg / 21,6 kg (EOS Gracil W)
- Stone filling
- 20 kg
- Power extension required
- no
- Electrical connection
- 400 V 3N ~ 50/60 Hz
- Power vaporizer
- 750 W
- Fuse protection (control unit)
- 3 x 16 A
- Dimensions H/W/D, in cm
- 76 / 56 / 25 (EOS Bi-O Gracil) 74 / 56 / 27,5 (EOS Bi-O Gracil W)
- For sauna cabin size (4,5 / 6,0 / 7,5 / 9,0 kW)
- 4 - 6 m³ / 6 - 8 m³ / 7 - 10 m³ / 9 - 14 m³
- Min. size of air intake and outlet (4,5 / 6,0 / 7,5 / 9,0 kW)
- 35 x 5 cm / 35 x 6 cm / 35 x 6 cm / 35 x 6 cm
- Weight without stones and packaging (4,5 / 6,0 / 7,5 / 9,0 kW)
- 26,0 kg / 26,5 kg / 27,0 kg / 27,5 kg (EOS Bi-O Gracil) 23,0 kg / 23,5 kg / 24,0 kg / 24,5 kg (EOS Bi-O Gracil W)
- Stone filling
- 20 kg
- Power extension needed
- no
- Power
- Item no.
- 6,0 kW
- 946755
- 7,5 kW
- 946756
- 9,0 kW
- 946757
- 6,0 kW black
- 948196
- 7,5 kW black
- 947243
- 9,0 kW black
- 947244
- Power
- Item no.
- 6,0 kW
- 947157
- 7,5 kW
- 947158
- 9,0 kW
- 947159
- 6,0 kW black
- 948197
- 7,5 kW black
- 947245
- 9,0 kW black
- 947246
- Power
- Item no.
- 7,5 kW
- 946987A
- 9,0 kW
- 946988A
- 7,5 kW black
- 947247
- 9,0 kW black
- 947248
- Power
- Item no.
- 7,5 kW
- 947161A
- 9,0 kW
- 947162A
- 7,5 kW black
- 947327
- 9,0 kW black
- 947328
