EOS Mythos series 2.0 kW
Точные сроки и условия подтвердит менеджер перед оплатой.
Отправить конфигурацию товара менеджеру и обсудить детали
Описание товара
General description
EOS Mythos floor‑standing sauna heaters are available in two stone‑volume versions: 35 kg (S35) and 45 kg (S45). Each model offers power options (7.5 kW / 9.0 kW for S35, 12.0 kW / 15.0 kW for S45) suitable for sauna cabins up to approximately 14 m³ and 25 m³ respectively. All heaters can be equipped with optional Cubius sauna stones.
S35 series
EOS Mythos S35 floor‑standing heater with a stone volume of 35 kg. Available finishes: anthracite (pearl effect), black, white. Models with inclusive Cubius stones are offered in black and white. Optional Cubius stones can be added to the anthracite version.
S45 series
EOS Mythos S45 floor‑standing heater with a stone volume of 45 kg. Available finishes: anthracite (pearl effect), black, white, “Water Reflection”, dark bronze. Models with inclusive Cubius stones are offered in black, white, “Water Reflection” and dark bronze. Optional Cubius stones can be added to the anthracite version.
Vapor models
External vaporizer versions for flexible climate forms are offered for both S35 and S45 series. Finishes include anthracite (pearl effect), matt black, matt white, and “Water Reflection”. Vaporizers can be installed on the left side, right side, or both sides, with optional heater guard rail.
Accessories
Optional accessories: Cubius sauna stones, Cubius Loop sauna stones, vaporizer, EOSafe L safety system, wooden heater guard with mounting brackets. Additional kits: EOS Mythos + EOS Scent Trophy W with Cubius stones (special heights), EOS Mythos + EOS Scent Trophy S with heater guard rail, EOS Mythos Vapor + EOSafe L.
Характеристики
- Мощность
- 2,0 kW
- Electrical connection
- 400 V 3N ~ 50/60 Hz
- Dimensions H/W/D, in cm
- 84 / 42 / 37 (EOS Mythos S35) 84 / 50 / 37 (EOS Mythos S45)
- For sauna cabin size (7,5 / 9,0 / 12,0 / 15,0 kW)
- 8 - 12 m³ / 10 - 14 m³ / 14 - 18 m³ / 18 - 25 m³
- Min. size air inlet and outlet (7,5 / 9,0 / 12,0 / 15,0 kW)
- 35 x 5 cm / 35 x 6 cm / 35 x 7 cm / 35 x 9 cm
- Fuse protection control unit
- 3 x 16 A
- Weight withouth rocks
- 34 kg (EOS Mythos S35) 40 kg (EOS Mythos S45)
- Stone filling
- 35 kg (EOS Mythos S35) 45 kg (EOS Mythos S45)
- Power extension required (7,5 - 9 kW / 12 - 15 kW)
- no / PEB 10
- Electrical connection
- 230 V 1N ~ 50 Hz
- Vaporizer power
- 2,0 kW / 3,0 kW
- Vaporizer dimensions H/W/D, in cm
- 84 / 8 / 37
- Vaporizer water tank volume
- 10 l
- Connection control unit - vaprozer
- 5 x 1,5 mm²
- Power
- Item no.
- 7,5 kW
- 945488
- 9,0 kW
- 945489
- 7,5 kW
- 946066
- 9,0 kW
- 946067
- 7,5 kW
- 945988
- 9,0 kW
- 945989
- 7,5 kW
- 949591
- 9,0 kW
- 949592
- 7,5 kW
- 949408
- 9,0 kW
- 949409
- Power
- Item no.
- 12,0 kW
- 945490
- 15,0 kW
- 945491
- 12,0 kW
- 946068
- 15,0 kW
- 946069
- 12,0 kW
- 945991
- 15,0 kW
- 945992
- 12,0 kW
- 949589
- 15,0 kW
- 949590
- 12,0 kW
- 949406
- 15,0 kW
- 949407
- Power
- Item no.
- 3,0 kW
- 945572
- 3,0 kW
- 945493
- 6,0 kW
- 946250
- 2,0 kW
- 945571
- 2,0 kW
- 945492
- 4,0 kW
- 946253
- 3,0 kW
- 945902
- 3,0 kW
- 945906
- 6,0 kW
- 946262
- 2,0 kW
- 945901
- 2,0 kW
- 945905
- 4,0 kW
- 946265
- 3,0 kW
- 945900
- 3,0 kW
- 945904
- 6,0 kW
- 946256
- 2,0 kW
- 945899
- 2,0 kW
- 945903
- 4,0 kW
- 946259
- 3,0 kW
- 949595
- 3,0 kW
- 949596
- 6,0 kW
- 949602
- 2,0 kW
- 949593
- 2,0 kW
- 949594
- 4,0 kW
- 949599
- 3,0 kW
- 949404
- 3,0 kW
- 949405
- 6,0 kW
- 949415
- 2,0 kW
- 949402
- 2,0 kW
- 949403
- 4,0 kW
- 949412
