EOS Mythos series 3.0 kW
Точные сроки и условия подтвердит менеджер перед оплатой.
Отправить конфигурацию товара менеджеру и обсудить детали
Описание товара
EOS Mythos S35 Floor-standing Sauna Heater
EOS Mythos S35 floor-standing sauna heater with a stone volume of 35 kg – available in 7.5 kW and 9.0 kW versions for sauna cabins up to approx. 14 m³.
Available finishes: anthracite (with optional Cubius stones), black (with inclusive Cubius stones), and white (with inclusive Cubius stones).
EOS Mythos S45 Floor-standing Sauna Heater
EOS Mythos S45 floor-standing sauna heater with a stone volume of 45 kg – available in 12.0 kW and 15.0 kW versions for sauna cabins up to approx. 25 m³.
Available finishes: anthracite (with optional Cubius stones), black, white, «Water Reflection», and dark bronze (all with inclusive Cubius stones).
EOS Mythos Vapor External Vaporizer
EOS Mythos S35 Vapor and S45 Vapor models feature an external vaporizer for flexible climate forms. Available in anthracite pearl effect, matt black, white, and «Water Reflection» finishes.
Vaporizer configurations include left, right, or left+right placement, with optional heater guard rail for certain finishes.
Accessories and Safety Options
Optional accessories include Cubius sauna stones, Cubius Loop sauna stones, vaporizer, EOSafe L safety system, and a wooden heater guard with mounting brackets.
Compatible accessory combinations: EOS Mythos + EOS Scent Trophy W + Cubius-sauna stones (special heights), EOS Mythos + EOS Scent Trophy S + heater guard rail, EOS Mythos Vapor + EOSafe L.
Характеристики
- Мощность
- 3,0 kW
- Electrical connection
- 400 V 3N ~ 50/60 Hz
- Dimensions H/W/D, in cm
- 84 / 42 / 37 (EOS Mythos S35) 84 / 50 / 37 (EOS Mythos S45)
- For sauna cabin size (7,5 / 9,0 / 12,0 / 15,0 kW)
- 8 - 12 m³ / 10 - 14 m³ / 14 - 18 m³ / 18 - 25 m³
- Min. size air inlet and outlet (7,5 / 9,0 / 12,0 / 15,0 kW)
- 35 x 5 cm / 35 x 6 cm / 35 x 7 cm / 35 x 9 cm
- Fuse protection control unit
- 3 x 16 A
- Weight withouth rocks
- 34 kg (EOS Mythos S35) 40 kg (EOS Mythos S45)
- Stone filling
- 35 kg (EOS Mythos S35) 45 kg (EOS Mythos S45)
- Power extension required (7,5 - 9 kW / 12 - 15 kW)
- no / PEB 10
- Electrical connection
- 230 V 1N ~ 50 Hz
- Vaporizer power
- 2,0 kW / 3,0 kW
- Vaporizer dimensions H/W/D, in cm
- 84 / 8 / 37
- Vaporizer water tank volume
- 10 l
- Connection control unit - vaprozer
- 5 x 1,5 mm²
- Power
- Item no.
- 7,5 kW
- 945488
- 9,0 kW
- 945489
- 7,5 kW
- 946066
- 9,0 kW
- 946067
- 7,5 kW
- 945988
- 9,0 kW
- 945989
- 7,5 kW
- 949591
- 9,0 kW
- 949592
- 7,5 kW
- 949408
- 9,0 kW
- 949409
- Power
- Item no.
- 12,0 kW
- 945490
- 15,0 kW
- 945491
- 12,0 kW
- 946068
- 15,0 kW
- 946069
- 12,0 kW
- 945991
- 15,0 kW
- 945992
- 12,0 kW
- 949589
- 15,0 kW
- 949590
- 12,0 kW
- 949406
- 15,0 kW
- 949407
- Power
- Item no.
- 3,0 kW
- 945572
- 3,0 kW
- 945493
- 6,0 kW
- 946250
- 2,0 kW
- 945571
- 2,0 kW
- 945492
- 4,0 kW
- 946253
- 3,0 kW
- 945902
- 3,0 kW
- 945906
- 6,0 kW
- 946262
- 2,0 kW
- 945901
- 2,0 kW
- 945905
- 4,0 kW
- 946265
- 3,0 kW
- 945900
- 3,0 kW
- 945904
- 6,0 kW
- 946256
- 2,0 kW
- 945899
- 2,0 kW
- 945903
- 4,0 kW
- 946259
- 3,0 kW
- 949595
- 3,0 kW
- 949596
- 6,0 kW
- 949602
- 2,0 kW
- 949593
- 2,0 kW
- 949594
- 4,0 kW
- 949599
- 3,0 kW
- 949404
- 3,0 kW
- 949405
- 6,0 kW
- 949415
- 2,0 kW
- 949402
- 2,0 kW
- 949403
- 4,0 kW
- 949412
